Ranger RC
26
Settings in the menu
4.3 Scale settings (SCALE)
4.3.1 SCALE1/SCALE2 – Selecting scale
This menu item only appears if an analog second scale or a weighing platform is con-
nected.
4.3.2 CAL – calibration (adjustment)
This menu item is not available for certified scales without internal calibration weight.
4.3.3 DISPLAY – weighing unit and display accuracy
Internal For scales with an internal calibration weight:
1. Unload scale.
2. Activate menu item CAL with
Yes . The scale calibrates with the internal calibra-
tion weight. -Int CAL- appears in the display. After calibration is completed,
-donE- appears briefly in the display, and the scale automatically returns to
weighing mode.
External For scales without an internal calibration weight:
1. Unload scale.
2. Activate menu item CAL with
Yes . The scale determines the zero point.
–0- appears in the display. The calibration weight to be placed on the scale then
flashes in the display.
3. If necessary, change the weight value displayed with No .
4. Place the calibration weight on the scale and confirm with Yes .
The scale calibrates with the calibration weight loaded. After calibration is com-
pleted, -donE- appears briefly in the display, and the scale automatically returns
to weighing mode.
UNIt1 Select weighing unit 1: g, kg, oz, lb, t
UNIt2 Select weighing unit 2: g, kg, oz, lb, t
rESOLU Select readability (resolution), model-dependent
UNt.rOLL
When UNT.rOLL is switched on, the weight value can be displayed in all available
units and as pieces with
Count Weight .
Notes • On certified scales, the weighing units oz and lb are displayed with the symbol *.
• On certified scales, resolutions that deviate from the scale definition are displayed
without a weighing unit and with the symbol
*.
• On dual-range/dual interval scales, resolutions marked with |<–> 1/2| are
divided up into 2 weighing ranges / intervals, e.g. 2 x 3000 d.
