32
Trooper Count Scale
General Specifications
7.2 Specifications
Capacity x Readability TC3RS TC6RS TC15RS TC30RS
Enhanced 6 lb X 0.001 lb 15 lb X 0.002 lb 30 lb X 0.005 lb 60 lb X 0.0 lb
Enhanced 3 kg X 0.0005 kg 6 kg X 0.001 kg 15 kg X 0.002 kg 30 kg X 0.005 kg
Enhanced 3000 g X 0.5 g 6000 g X 1 g 15000 g X 2 g 30000 g X 5 g
Enhanced 96 oz X 0.02 oz 240 oz X 0.05 oz 480 oz X 0.1 oz 960 oz X 0.2 oz
Type Approved 1 6 lb X 0.002 lb 15 lb X 0.005 lb 30 lb X 0.01 lb 60 lb X 0.02 lb
Type Approved 1 3 kg X 0.001 kg 6 kg X 0.002 kg 15 kg X 0.005 kg 30 kg X 0.01 kg
Type Approved 1 3000 g X 1 g 6000 g X 2 g 15000 g X 5 g 30000 g X 10 g
Type Approved 1 96 oz X 0.05 oz 240 oz X 0.1 oz 480 oz X 0.2 oz 960 oz X 0.5 oz
Note: All Trooper Count models are designed to meet the type approval requirements of NIST Handbook 44, Weights
and Measures Regulations of Canada, OIML R76 and EEC EN45501.
Ambient conditions
The technical data is valid under the following ambient conditions:
Ambient temperature
5°C to 40°C / 41°F to104°F
Relative humidity 10%.......95%, noncondensing
Height above sea level up to 4000m
Platform Size (w x d) (in/mm) 13.5 X 9 / 340 X 230
Scale Dimensions (w x d x h) (in/mm) 13.5 X 14.5 X 4.5 / 343 X 368 X 114
Shipping Dimensions (w x d x h) (in/mm) 17 X 17 X 8.5 / 422 X 422 X 216
Weight (lb/kg) 8.6 / 3.9
Type Approved Resolution 1:3000
Maximum Resolution 1:6,000 - 1:7,500 depending on model
Stabilization time 1 - 4 seconds depending upon mode
Weighing units lb, kg, g, oz
Display 3 backlit LCD Displays - 7 segment, 12 mm high
Power AC Adapter or 6 alkaline C-type batteries
Typical Battery Life Up to 100 hours
Span Calibration 1/3, 2/3, or full capacity
Linearity Calibration (3-point calibration) 0, 2/3 and full capacity
Auto-zero tracking Off, 0.5, 1, or 3 divisions
Protection IP42
Operating Temperature 41°F to 104°F / 5°C to 40°C
Storage Temperature -40°F to 140°F / -40°C to 60°C
Construction: ...........
Internal Frame Cast Aluminum ............
Weighing Platform Stainless Steel ............
Housing ABS ...........
Keypad Overlay Polyester
