EN-25 FD Series
TABLE 5-2. SPECIFICATIONS.
Note: Product specifications are subject to change without any obligation on the manufacturer.
Model FD3H FD6H FD15H
Capacity x Readability
(Max x d non-approved)
3 kg x 0.0001 kg
3000 g x 0.1 g
6 lb x 0.0002 lb
96 oz x 0.005 oz
96 oz x 1/4 oz
6 lb 0 oz x 0.1 oz
6 lb 0 oz x 1/4 oz
6 kg x 0.0002 kg
6000 g x 0.2 g
15 lb x 0.001 lb
240 oz x 0.01 oz
240 oz x 1/4 oz
15 lb 0 oz x 0.1 oz
15 lb 0 oz x 1/4oz
15 kg x 0.001 kg
15000 g x 1 g
30 lb x 0.001 lb
480 oz x 0.02 oz
480 oz x 1/4 oz
30 lb 0 oz x 0.1 oz
30 lb 0 oz x 1/4 oz
Maximum displayed resolution
Linearity
1:30000 1:30000 1:30000
0.0002 kg 0.0004 kg 0.002 kg
±0.0002 kg ±0.0004 kg ±0.002 kg
Power
9-12 VDC 0.5-0.8 A AC Adapter
Internal rechargeable sealed lead-acid battery
Checkweigh indication
Application modes
Weight display
5-digit 19 mm high digits, 7-segment back lit LCD display
(with fractional ounce and battery status indicator)
Weighing, Checkweighing, Percentage
3 LEDs (yellow, green, red) with configurable alert beeper
Weighing units
g, kg, lb, oz (decimal/fractional), lb:oz (decimal/fractional oz)
Keyboard 4 - button membrane switch
Typical battery life 120 hours with 15 hour recharge time
Tare range To capacity by subtraction
Stabilization time Within 2 seconds
Auto zero tracking
Operating temperature range
Off, 0.5, 1 or 3 divisions
-10 °C to 40 °C / 14 °F to 104 °F
Storage temperature range
Approved temperature range
-40 °C to 70 °C / -40 °F to 158 °F
0 °C to 40 °C / 32 °F to 104 °F
Protection
Construction
IP43
304 Stainless steel housing and platform
Scale weight
Shipping weight
3.6kg / 8.0lb
5kg / 11lb
Pan size (DxW)
Scale dimensions (DxWxH)
Shipping dimensions (DxWxH)
209 x 209mm / 8.2 x 8.2 in.
300 x 223 x 71 mm / 9 x 12 x 2.8 in.
400 x 320 x 185mm / 15.8 x 12.6 x 7.3in.
Repeatability
