FD Series EN-8
Figure 3-3. Display.
Item Description
1 Control buttons
2 Display
3 Data Label
4 Weighing pan
5 Adjustable leveling feet
6 Connection for AC adapter
7 Connection for optional foot switch
8 Security Cover
9 Power and Zero button
10 Gross/Net/Tare and Unit button
11 Target/Menu button
12 Tare button
13 Tare indicator
14 Net indicator
15 Leveling indicator
16 Checkweigh mode indicator
17 Center of Zero indicator
18 Stable indicator
19 Yellow Under LED
TABLE 3-1. PARTS AND CONTROLS.
Item Description
20 Green Accept LED
21 Red Over LED
22 Not used
23 Minus sign
24 Not used
25 7-segment display
26 Fractional ounce symbol
27 Battery charge symbol
28 Kilogram unit symbol
29 Gram unit symbol
30 Ounce unit symbol
31 Pound:Ounce unit symbol
32 Pound unit symbol
33 Tare indicator
34 Net indicator
35 Checkweigh mode indicator
36 Pound:Ounce separator
37 Center of Zero indicator
38 Stable indicator
22
23
24
29
30
28
31
32 33 34 35 36 37 38
25 26 27
