High Lifter Lift Kit for Can-Am Maverick 1000 (2013) - Signature Series - Manual (Page 4)

4
Front Lift Installation
1) Place transmission in park. Place jack under center of front end and lift until front wheels clear the ground.
Be careful to support properly so that it is securely supported so that A-arms and shocks can droop to full
extension.
2) Remove front wheels.
3) Disconnect the top of shock from the frame.
4) Insert the spacer block into the shock mount with the small hole end going in first.
5) Attach the spacer block to the fame by inserting the ¼” x 2 ¼” hex bolt through existing holes in the frame
and block. Fasten it loosely with a ¼” lock nut, so that you can pivot the block to align holes to the lift
bracket.
