High Lifter Lift Kit for Polaris 800 RANGER RZR “S” and “4” - Signature Series User Manual
Page 7
7
9) Next you need to connect the small lift plate to the UTV using the shock mount tabs were the shock
was originally connected.
10) You will need to use one large spacer, one small spacer and 10x65mm hex bolt. Place the small
spacer between the large lift bracket, the large spacer between the shock mount tabs.
11) Place the small lift plate to the inside of the rear shock mount tabs between the spacer and the shock
mount tab. Fasten the plates with a 10mm lock nut.
