Front lift installation – High Lifter Lift Kit for Polaris 800 RANGER RZR “S” and “4” - Signature Series User Manual
Page 3
3
Front Lift Installation
1) Place UTV transmission in park. Place jack under center of UTV front end and lift until front wheels
clear the ground. Be careful to support UTV properly so that it is securely supported so that A-arms
and shocks can droop to full extension.
2) Remove front wheels.
3) Disconnect the top of the front shocks from the shock mount tabs on both sides of the UTV.
4) Insert one of the front lift brackets into the inside of the shock mount tabs.
5) Place the Large Spacer into the shock mount tab. Place it between the lift bracket and the shock
mount tab.
6) Next place the other lift bracket on the outside of the shock mount tabs, to the side that faces the rear.
