Issue 5.6.D IPDirector Version 5.6 – User Manual – Part 2 – Logging
EVS Broadcast Equipment – May 2009
24
C
REATE A
N
EW
L
OG
W
INDOW
The Create a New Log window always contain a Log Information tab. It can also
contain a Automatic keywords tab if a profile for Automatic Keywords is associated
to the log sheet profile.
The following table describes the fields available in the Create a New Log window:
Field Description
Timecode value Timecode grabbed from the relevant recorder defined in
step 2 or from the PC in case the Link to PC Timecode
button has been pressed.
Level Rating A rating can be given to an event from no stars to ***.
Highlight Colours Set of colours which can be selected in order to highlight
the log line with the selected colour.
Log entries can thus be displayed with a different colour
in the log sheet. They will be highlighted with these
colours in the Database Explorer grid. The operator can
then search on the colours in the DB Explorer.
Remember Color
Selection checkbox When the checkbox is selected, the focus will be placed
by default on the selected colour square next time the
Create a New Log window opens.
Description To add alphanumeric free text from the keyboard.
This will appear in the Description column of the log
sheet for the corresponding log, as well as in the
Description field of the log sheet for the log line
selected.
Keywords Up to 10 keywords can be added per event.
They will appear in the Keywords columns of the log
sheet for the corresponding log, as well as in the
Keywords field of the log sheet for the log line selected.
Automatic Keywords Displays the user fields defined for the log sheet profile
associated to the log sheet.
