Example: 1xSLSM 6PH + 2 PLAY MIX
The BNC connectors to be used as record and play channels in an SLSM configuration
with 1xSLSM 6PH + 2 PLAY MIX need to be cabled as shown below:
Available U-Motion 10-Phase Configurations
The table below shows the available U-Motion 6 Phase configurations in HD with an XT3
6U server, and how the BNC connectors should be cabled:
IN6/OUT1 IN5/OUT2 IN4/OUT3 IN3/OUT4 IN2/OUT5 IN1/OUT6
#REC
SLSM
6x
#REC #PLAY
Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
1 0 1 PLAY
1 REC
1,5 REC
1,10 REC
1,4 REC
1,9 REC
1,3 REC
1,8 REC
1,2 REC
1,7 REC
1,1 REC
1,6
Example: 1xSLSM 10PH + 2 PLAY MIX
The BNC connectors to be used as record and play channels in an SLSM configuration
with 1xSLSM 10PH + 2 PLAY MIX need to be cabled as shown below:
