3.2. Supported Configurations
3.2.1. General Information on Supported
Configurations
Overview on Supported Configuration Types
An XT3 server, equipped with V3X boards, supports the following configurations types:
• standard SD/HD configurations
• standard SD/HD XREC configurations (using secondary links for independent
recorders)
• SLSM SD/HD configurations
• SLSM SD/HD XREC configurations
• 3D/1080p configurations
• SLSM 3D/1080p configurations
Note
The feature
Mix on one channel
1
is available on all SD/HD configurations.
Number of Record and Play Channels
The number of record and play channels for a given configuration is defined in the
Channels tab, in the Base settings. See section "Base Settings" on page 105.
The number of play and record channels available may differ depending on the chassis
and on the configurations running on the XT3 server:
• Mutlicam LSM mode, when the EVS server is controlled by the Remote Panel
• Spotbox mode, when the EVS server is controlled by industry-standard protocols
such as Sony BVW75, VDCP, Odetics, DD35, EVS’ AVSP, IPDP, EditRec or LinX
API.
1
Feature that allows using the secondary link of the codec module of a player channel on the V3X board (J3) as
the preview channel to provide the PGM/PRV mode with a single codec module.
