nanoAir – Version 1.00 – User Manual
EVS Broadcast Equipment – April 2013
Issue 1.00.A
19
4. Operation
4.1 Introduction
This chapter explains how to use nanoAir, in ingest or playout mode. Both modes are not
available at the same time.
The nanoAir window opens as soon as you have clicked the Select button at the end of
the Server Configuration process.
4.2 Overview of NanoAir Main Window
The nanoAir user interface consists of five main areas, including the Menu bar. The areas
are highlighted on the following screenshots and shortly described in the table below.
The following screenshot show the Ingest pane with the clip library and the Playlist edition
pane.
3
2
1
4
