American Magnetics 185 & 186 Liquid Level Instruments (CE-Marked) - Manual (Page 19)

Rev. 3 9
Introduction
Specifications
Physical
Dimensions (Standard): 97 mm H x 213 mm W x 282 mm D
(3.8" H x 8.4" W x 11.1" D)
Weight (Standard): 1.6 kg (3.6 lbs.)
Dimensions (Rack Mount): 89 mm H x 483 mm W x 282 mm D
(3.5" H x 19" W x 11.1" D)
Weight (Rack Mount): 2.0 kg (4.3 lbs.)
Environmental
Ambient Temperature: Operating: 0 °C to 50 °C (32 °F to 122 °F)
Nonoperating: − 20 °C to 60 °C ( − 4 °F to 140 °F)
Relative Humidity: 0 to 95%; non-condensing
a. Under extreme radiated electromagnetic field conditions (3V/m at 450 MHz to 610
MHz), the accuracy may be degraded by an additional ± 0.7%.
b. Units configured for Japan or South Korea cannot be configured for operation at
other voltages without an internal transformer change, and vice-versa.
