Introduction
Model 185 Front Panel Layout
1.2 Model 185 Front Panel
1
Activity LED
6
MIN calibration push-button
2
LED display
7
Approximate calibration push-button
3
HI level LED
8
MAX calibration push-button
4
LO level LED
9
Control mode rotary switch
5
Power toggle switch
10
Raise/lower toggle switch
11
Units mode toggle switch
