D r i v e s 69
If your computer came with a CD drive, use the spare connector on
the existing interface cable. Otherwise, use the IDE interface cable
provided in the drive kit.
3 Connect the data, power, and audio cables to the drive.
4 Check all cable connections, and fold cables out of the way to provide
airflow for the fan and cooling vents.
5 If the drive bay was previously empty, remove the front-panel insert
from the front panel.
a Remove the front-panel cover with your fingers.
b Remove the insert by pressing it until it pops free.
c Replace the front-panel piece by snapping it into place.
Small Desktop Computer
1 Gently slide the drive into place until the tabs securely click into
position.
2 Connect the data, power, and audio cables to the drive.
1 Interposer board
2 Notch on inside of cover
3 Interposer board tab
