22 I n s i d e t h e C o m p u t e r
www
.dell.com | support.dell.com
S m a l l M i n i -To w e r C o m p u t e r
1 Cover release buttons (2) 8 AC power connector
2 Hard drive 9 Padlock ring
3 Internal speaker 10 Microprocessor and airflow shroud
4 Chassis intrusion switch 11 Power supply
5 System board 12 3.5-inch floppy drive
6 Expansion-card slots 13 CD/DVD drive
7 I/O ports and connectors
