Working Advice
General Sawing Instructions
f
For all cuts, it must first be ensured that the
saw blade at no time can come in contact
with the fence, screw clamps or other ma-
chine parts. Remove possibly mounted aux-
iliary stops or adjust them accordingly.
Protect the saw blade against impact and shock.
Do not subject the saw blade to lateral pressure.
Do not saw warped/bent workpieces. The work-
piece must always have a straight edge to face
against the fence.
Long workpieces must be underlaid or support-
ed at their free end.
Position of the Operator (see figure N)
f
Do not stand in a line with the saw blade in
front of the machine. Always stand aside of
the saw blade. This protects your body
against possible kickback.
– Keep hands, fingers and arms away from the
rotating saw blade.
– Do not cross your arms when operating the
tool arm.
Permissible Workpiece Dimensions
Maximal workpiece sizes:
Minimal workpiece sizes
(= all workpieces that can be clamped left or
right from the saw blade with the provided
quick-action clamp 21):
145 x 40 mm (length x width)
Cutting capacity, max. (0°/0°): 85 mm
Replacing Insert Plates (see figure O)
The red insert plates 10 can become worn after
long use of the machine.
Replace defective insert plates.
– Bring the power tool into the working posi-
tion.
– Unscrew the screws 59 using the provided
Phillips screwdriver and remove the old in-
sert plates.
– Insert the new insert plates.
– Set the bevel angle to 47° (leftward).
– Push locking lever 41 and completely lower
the tool arm.
– Position the insert plate approx. 2 mm away
from the saw blade. Make sure that the saw
blade does not come in contact with the in-
sert plates throughout the complete possible
ripping length.
– Refasten the insert plate with the screws.
– Repeat the work steps for the other insert
plate in the same manner.
Mitre/Bevel Angle Height x Width
[mm]
Horizontal Vertical
0° 0° 85 x 305
45° 0° 85 x 216
0° 45° (left-
ward)
50 x 305
0° 45° (right-
ward)
32 x 305
45° 45° (left-
ward)
50 x 216
45° 45° (right-
ward)
32 x 216
