English | 39
Bosch Power Tools 1 609 929 X04 | (13/7/10)
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
Intended Use
The power tool is intended as a stationary ma-
chine for making straight lengthways and cross-
ways cuts in wood. In this, horizontal mitre an-
gles from –52° to +60° as well as vertical bevel
angles from 47° (leftward) to 46° (rightward)
are possible.
The capacity of the power tool is designed for
sawing hardwood and softwood.
The power tool is not suitable for cutting alumin-
ium or other non-ferrous metals or alloys.
Product Features
The numbering of the components shown refers
to the representation of the power tool on the
graphic pages.
1 Dust bag
2 Transport handle (front)
3 Clamp for handle
4 Tongue for grade-adjustment of handle
5 Handle
6 Button for releasing locking lever 41
7 Saw blade
8 Retracting blade guard
9 Roller
10 Insert plate
11 Locking bracket
12 Locking knob for various mitre angles
(horizontal)
13 Lever for mitre angle adjustment
(horizontal)
14 Clamping lever for various bevel angles
(vertical)
15 Detents for standard mitre angles
16 Saw table
17 Mounting holes
18 Fence
19 Fence extension
20 Locking screw for fence extension
21 Quick-action clamp
22 Angle indicator (vertical) for rightward bevel
angle range
23 Slide device
24 Cable holder
Only for EC countries:
Do not dispose of power tools into household waste!
According the European Guideline 2002/96/EC for Waste
Electrical and Electronic Equipment and its implementa-
tion into national right, power tools that are no longer us-
able must be collected separately and disposed of in an
environmentally correct manner.
Symbol Meaning
0 – 45°
