38 | English
1 609 929 X04 | (13/7/10) Bosch Power Tools
Danger of crushes or contusions! When transporting, en-
sure that your fingers are positioned around the trans-
port handle.
Indicates the individual steps for adjusting the handle.
Indicates the individual steps for adjusting the bevel an-
gle.
Left column:
– Bevel angle range
Saw blade is inclined to the left
Right column:
– Bevel angle range
Saw blade is inclined to the right
– Bevel angle range
Complete tilting range of the tool arm
Indicates the position of the locking lever for locking the
tool arm and for adjusting the bevel angle.
Symbol Meaning
45°– 0
0 – 45°
45°+
