Bevel angle range (see figure K)
– Pull the right fence extension 19 completely
outward. (see “Extending the Fence”,
page 45)
– Loosen the clamping lever 14.
– Lightly tilt the tool arm leftward out of the 0°
position via handle 5 and turn knob 39 until
the desired bevel angle range is indicated.
– Tilt the tool arm via handle 5 to the right until
angle indicator 22 indicates the desired bev-
el angle.
– Hold the tool arm in this position and retight-
en the clamping lever 14.
The clamping force of the clamping lever
must securely hold the position of the tool
arm at any bevel angle.
Standard 0° Bevel Angle
To enable simple and swift resetting of the
standard 0° bevel angle, knob 39 will engage in
the
bevel angle range.
– Tilt the tool arm from right to left over the 0°
position.
Bevel angle range
– Pull both fence extensions 19 completely
outward. (see “Extending the Fence”,
page 45)
– Loosen the clamping lever 14.
– Lightly tilt the tool arm leftward out of the 0°
position via handle 5 and turn knob 39 until
the desired bevel angle range is indicated.
– Tilt the tool arm via handle 5 to the left or
right until angle indicator 31 or 22 indicate
the desired bevel angle.
– Hold the tool arm in this position and retight-
en the clamping lever 14.
The clamping force of the clamping lever
must securely hold the position of the tool
arm at any bevel angle.
Standard 33.9° Bevel Angle
– Standard angle 33.9°:
Pull adjustment knob 32 completely outward
and turn it by 90°. Now tilt the tool arm via
the handle 5 until the tool arm can be heard
to engage.
Adjusting the Handle (see figure L)
For a more convenient hand position, the handle
5 can be turned to 4 different positions.
– Loosen clamp 3.
– Grasp and pull tongue 4 outward, then turn
handle 5 until it engages in the desired posi-
tion.
– Let go of tongue 4 again and lock clamp 3.
Starting Operation
f Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specified on the nameplate of the
machine. Power tools marked with 230 V
can also be operated with 220 V.
Switching On (see figure M)
– To start the machine, press the On/Off
switch 25 and keep it pressed.
Note: For safety reasons, the On/Off switch 25
cannot be locked; it must remain pressed during
the entire operation.
The locking lever 41 will only disengage the re-
tracting blade guard 8 after pressing button 6,
so that the tool arm can be lowered.
– For sawing, you must press button 6 in addi-
tion to actuating the On/Off switch.
Switching Off
– To switch off the machine, release the
On/Off switch 25.
