ENC 250™ SINGLE SECTION Mechanical Specifications
14
Connecting cable: Length = .61m [2 ft]
Armor Connector: DE-9P
Mechanical Specifications Digital
Resolution 5µm [0.0002 in.]
Grating pitch 100µm [0.00393 in]
Scale medium Reflective Metal Tape
Accuracy ± 15µm/M [0.00018 in/ft]
Max. cable length 22.9m [75 ft.] VRO / 10.7m [35 ft.] DRO
Measuring length 3240mm [127”] - 6040mm [237”]
Force required to move
reading head
± 3.3 Newtons [0.75 lbs]
Max. slew speed 1 M/sec [40 in/sec.]
Operating Environment:
Temperature
0° to 40° C [32° to 104°F]
Relative Humidity 20% to 95% (non-condensing)
Storage Environment:
Temperature
-40° to 60° C [-40° to 140°F]
Humidity 20% to 95% (non-condensing)
Weight w/cable 1 kg + 3.2kg/M [2.2 lbs. + 0.18 lbs/in] of measuring length
Reference Mark Interval 100mm [3.937”] Distance encrypted
