Chapter 3
3.1 Operations after POST Screen
After CMOS dis charge or BIO S flashing operation, the s ystem will display the following screen for your
fu rther operation. Pres s F1 key to continue or Del key to enter CMOS Setup.
Phoeni x – AwardBIOS v6.00PG, An Energy Star Ally
Copyright © 1984-2007, Phoenix Technologies, LTD
ASB-L701 V019
Main Processor : Intel® Atom™ 1.60GHz(133x12)
Memory Testing :515008K OK + 8M shared memory
CPU Brand Name : Intel® Atom™ CPU N270
C1E BIOS Supported
Hyper-Threading Technology CPU Detected (Hyper-Threading Technology
Enabled
)
Memory Frequency For
DDR 2 533
IDE Channel 0 Mas ter : None
IDE Channel 0 Slave : None
IDE Channel 1 Mas ter : None
IDE Channel 1 Slave : None
CMOS checksum error – Defaults loaded
Press
F1
to continue,
DEL
to enter SETUP
08/14/2010-Silverthrone-6A79KAPXC-00
After optimizing an d e xiting CMOS Setup, the PO ST screen display ed f or the first time is as follows
a nd includes bas ic information on BIOS, C PU , memory, and storage d evices.
Phoeni x – AwardBIOS v6.00PG, An Energy Star Ally
Copyright © 1984-2007, Phoenix Technologies, LTD
ASB-L701 V019
Main Processor : Intel® Atom™ 1.60GHz(133x12)
Memory Testing :515008K OK + 8M shared memory
CPU Brand Name : Intel® Atom™ CPU N270
C1E BIOS Supported
Hyper-Threading Technology CPU Detected (Hyper-Threading Technology
Enabled
)
Memory Frequency For
DDR2 533
IDE Channel 0 Master : None
IDE Channel 0 Slave
: None
IDE Channel 1 Master : None
IDE Channel 1 Slave : None
Press
DEL
to enter SETUP,
F12
to Enter Boot Menu
08/14/2010-Silverthrone-6A79KAPXC-00
Press F12 key to enter Boot Menu during POST, as s ho wn by the follow ing figure.
Boot Menu
== Select a Boot First device ==
