Page 26
PCH 7591
15 inch Atom Fanless Panel PC
© Copyright 2012 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
14628 Central Ave.
Chino, CA91710
Tel:909.597.7588, Fax:909.597.1939
Signal Name
Pin#
Pin#
Signal Nam e
+5V
1
2
+5V
Gro und
3
4
Ground
+3.3V
5
6
+3.3 V
A0M
7
8
A4M
A0P
9
1 0
A4P
Gro und
11
1 2
Ground
A1M
13
1 4
A5M
A1P
15
1 6
A5P
Gro und
17
1 8
Ground
A2M
19
2 0
A6M
A2P
21
2 2
A6P
Gro und
23
2 4
Ground
CLK1M
25
2 6
CLK2M
CLK1P
27
2 8
CLK2P
Gro und
29
3 0
Ground
SC _DDC
31
3 2
SD_DD C
Gro und
33
3 4
Ground
A3M
35
3 6
A7M
A3P
37
A3M
A7P
NC
39
4 0
NC
20. LVD S2
for dual 24 bit
24-bit LVDS output connector: Fully s upported b y C HR ONTEL
CH 7038B
chips et, the interf ace features single and dual channel 18-bit and 24-bit output with max imum
resolution support up to 1600*1200. The format of connected displ ay screen is OPENLDI. Model
name of the in terface con nec tor is Hirose D F13-4 0DP-1.25V.
