FPC 71X0 User Manual 4-16
4.4 Connectors and Pin Assignment
The table below lists the function of each of the board’s connectors.
Label Function
CN1 Inverter BKL Connector
CN2 4 Pin Power Connector
CN3 USB Connector
CN4 USB Connector
J1 PW/Reset Switch and Indicator Connector
J2 MSR Connector
J3 COM3/COM4 D-SUB 9Pin Connector
J4 COM2 + CRT (D-SUB 9Pin+D-SUB 15Pin Connector)
JP5 Digital 4-in 4-out I/O Connector
LAN1, LAN2 RJ45 + USB0/1, USB2/3 Connectors
SATA1, ATA2 SATA HDD Connector
FAN1, FAN2 CPU Fan Power Connector
I_SP Internal Speaker Connector
PW_IN DC Power In (DC12V)
COM1 COM Port Connector
COM5 COM Port Connector
COM6 COM Port Connector
AU1 Line Out, Mic Connector
FDD1 Floppy Drive Connector
LPT1 Parallel Port (26Pin Header)
LCD1 LVDS Panel Output
MODEM1 Onboard Modem Connector
IDE1 IDE Connector
PS1 PS2 Keyboard &Mouse connector
* Not Default Connector
