Maintenance
35
4.5 Replacing a Fan Module
A faulty fan module is indicated with a message on the LCD panel and
the audible alert sounds. Follow the procedure below to replace the
faulty fan module.
1. Loosen the screws then pull out the faulty fan module.
Note
• To turn off the audible alert, simultaneously press the Up and
Down buttons on the front panel twice.
• The following illustrations show A16R-FS RAID controllers,
however the same procedures apply to A12R-FS&SS, A16R-SS,
and A24R-FS&SS RAID systems.
B
2
A12R/U
A16R/U
Fan 2
Contrall
A24R/U
