92
Others 5
Product Name D-ILA Projector
Model Name DLA-X90R-B,DLA-X70R-B,DLA-X30-B,DLA-X30-W
*
1
Display Panel/Size
D-ILA device * 2 *3
0.7" (1920pixels x 1080pixels) x 3 (Total no. of pixels: Approx. 6.22million)
Projection Lens
2.0 x power zoom lens (1.4:1 to 2.8:1)
(Zoom/Focus: Power)
Light-source Lamp
220 W Ultra-high pressure mercury lamp [Part No.: PK-L2210U]
Average lifespan: 3000 hours (normal mode)
Screen Size Approx. 60" to 200" (Aspect ratio: 16:9)
Projection Distance Approx. 1.8m to 12m
Input compatibility signal (Reference page: 26, 27)
Display resolution
3840 dots x 2160 dots
1920 dots x 1080 dots
Input
terminal.
Video Input
1 system, RCA pin jack ×3
Y:1.0Vp-p, 75Ω
Pb/Cb, Pr/Cr:0.7Vp-p, 75Ω
(*) Also supports R / G / B Sync on G
HDMI Input
2 system, HDMI 19 pin × 2(HDCP compliant) * 4
Compatible with the HDMIv1.4a standard * 5
PC Input 1 system, D-Sub 15 pin VGA 90 70
Output
terminal
Trigger terminal
1 system, Φ 3.5mmDC Power Jack ( )
DC OUT 12V, 0.1A
3D synchro 3D synchro emitter dedicated terminal (1 system, mini DIN 3pin)
Control
terminal
RS-232C terminal 1 system , D-sub 9-pin (male) x1 (External control)
Remote terminal
1 system, stereo mini jack x1 (Remote Control)
LAN terminal 1 system, RJ-45 plug x1
Power Requirements AC 110V-240V 50/60Hz
Power Consumption
360W (3.5A Max) (Standby mode: 0.8W)
330W (3.2A Max) ( Standby mode: 0.8W)
Operation Environment
Temperature: 5ºC to 35ºC
Humidity: 20% to 80% (No condensation)
(Storage Temperature: -10℃ to 60℃ )
Installation Height Below 5000ft (1524 m)
Dimensions
(Width x Height x Depth)
About 455mmx179mmx472mm
(Excluding foot, lens, and other protruding parts)
Mass 15.4kg 90 70 / 14.9kg X7 30
Accessories (Reference page: 14)
Specifications
30
90 70
90 70
X7 30
