Operation
65
ENGLISH
[3-1] Lens Control
Use this function to adjust focus, zoom and shift. You can also turn image
pattern display ON or OFF and save lens position settings during adjustment.
Use the UP/DOWN keys to select an adjustment item. Press the
[BACK] key to return to the previous screen.
Items Explanation, operation, precautions, settings
It controls each motorized functions of the lens during the projector-installation.
Focus This function is used to adjust the focus.
Zoom This function is used to adjust the zoom.
Shift This function is used to adjust the shift.
Image Pattern It is possible to adjust the projection screen during adjustment of the focus zoom shift.
Settings: On, Off [On]
On During the adjustment, the image pattern is displayed.
The image pattern is displayed in conjunction with the above setting items.
Off The external input signal is displayed without displaying the image pattern.
Lock This sets the lens control to on/off.
Settings: On, Off [Off]
On It is not possible to adjust the above setting items. If the remote control button "LENS"
button is pressed, a warning message is issued.
Off This functions as lens control function.
Lens Memory Select Use this function to call up saved lens adjustment data. Configure to automatically adjust
the lens to the saved settings.
(*) There may sometimes be a slight difference between this and saved conditions.
Lens Memory Save Select lens focus, zoom and shift settings after adjustments have been made to save
the adjustment data at the time of selection. Select Memory 1, Memory 2 or Memory 3 in
accordance with your preference. You can also save as a different name when save data.
Lens Memory
Name Edit
You can edit the lens memory name.
(*) No. of characters is limited to 10.
(*) You can use capital and small alphabet letters, numbers and symbols.
Memory1
Memory2
Memory3
Select the user name you want to edit.
Press the [OK] key on the main unit or on the remote control to confirm and enter edit
mode.
(*) A "-" displays if the data is not saved.
(*) Press the [BACK] key on the main unit or on the remote control to exit edit mode.
Doing so will delete the content of your modifications.
Input cursor This displays the place where you will enter the characters. The cursor will move
automatically; it cannot be moved to the left or right.
Select cursor Move the cursor using the [UP], [DOWN], [LEFT], and [RIGHT] keys on the main unit or
on the remote control.
Move to the letter you want to enter and press the [OK] key on the main unit or on the
remote control to set the letter at the input cursor position in the NAME field.
Lock
Lens Memory Select
Lens Memory Save
Zoom
Shift
On Image Pattern
Auto Lens Cover
Lens Control
Focus
Lens Memory Name Edit
Off
Adjustments and settings in the menu (continued)
