Page 89
88
Instrument Panel
Gauges and Multi-Information Display Multi-Information Display
Power Flow Monitor
■
Displays engine and electric motor power flow – whether the system is assisting the
engine or charging the battery.
Power Flow Monitor
The displayed power flow may not correspond to
the ASST/CHRG indicators directly.
Electric Motor Assist Indicator (ASST)
Battery Charge in Progress (CHRG)
Operating
Not
operating
Engine
Operation
Icon
Power Flow
Power is supplied with the engine and
the electric motor is assisting the engine.
The electric motor is charging the IMA
battery.
Power is supplied with only the engine.
Power is supplied with only the engine
and the electric motor is charging the
IMA battery.
31SZT600book.indb 88
2010/04/28 13:41:24
2011 CR-Z
