RIDGID 535 - Manual (Page 3)

Ridge Tool Company
Tools For The Professional TM
300 Compact, 1233, 300, 535
Installing dies in diehead.
Fully open diehead (see Fig. 6).
Note: Ensure trigger has been disengaged (815A).
Insert dies with same number as shown on diehead into slots to “insert to line”
mark A (811A, 815A) or until detent (B) engages die (928). Rotate cam to align
size required with the mark.
Adjusting thread depth and length
See Fig. 5, 7a and 7b.
Oiling System
High quality thread cutting fluid is essential for the best threads and will help
to give the maximum die life. We recommend that only RIDGID thread cutting
fluid be used to protect the working of the machine. Keep oil filter screen in
reservoir clean.
Change oil when it is dirty or contaminated. RIDGID mineral and synthetic
oil is water washable. Folow local regulations concerning flushing of water
installations as soon as possible after completion. Check oil reservoir and add
oil to cover filter screen (see Fig. 8). Oil flow can be adjusted by the control
valve on the carriage (see Fig. 9), (No adjustment on 300).
Note: 400 Volt models of 535 have an oil flow control to direct oil to the diehead
when operating in reverse (See Fig. 14).
Maintenance
Oil bearings every 6 months (see Fig. 10). Clean jaw insert teeth with a wire
brush.
Replace complete set of inserts when they become worn (see Fig. 11). Check
brushes every 6 months for wear (see Fig. 12A) and replace when worn to
less than 12 mm. For all other service and maintenance take machine to a
RIDGID authorised service center.
IMPORTANT: This machine is supplied with RIDGID water-washable
mineral thread cutting oil designed to give optimal threads and prolong
die life. Before use, check your local regulations, which may prohibit the
use of mineral oil products on certain installations.
*→ 1996
DE
300 Kompakt, 1233, 300, 535
Bedienungsanleitung
WARNUNG! Lesen Sie diese Anweisungen
und die begleitende Sicherheitsbroschüre
sorgfältig, bevor Sie dieses Gerät benut-
zen. Bei Unklarheiten wenden Sie sich bitte an Ihre
RIDGID Vertriebsstelle, die Sie näher informiert.
Unkenntnis und Nichtbefolgung der Anweisungen
können zu elektrischen Schlägen, Feuer und/oder
schweren Verletzungen führen.
BEWAHREN SIE DIESE ANWEISUNGEN AUF!
TECHNISCHE DATEN
Gewindeschneidbereich
300
Kompakt
1233 300/300A 535
535 400V
Rohr
Bolzen
1/8”-2”
3/8”-2”
1/8”-3”
3/8”-2”
1/8”-2”
1/4”-2” (M52)
1/8”-2”
1/4”-2” (M52)
Abschneidleistung
Rohr
Bolzen
Fräsen
Geräuschpegel
Gewicht
Motor
1/8”-2”
3/8”-2”
1/4”-2”
79,5 dBA
52 kg
1,7 kW
1/8”-3”
3/8”-2”
1/4”-3”
80 dBA
56 kg
1,7 kW
1/8”-2”
1/4”-2”
1/4”-2”
80 dBA
48/90 kg
1,5 kW
1/8”-2”
1/4”-2”
1/4”-2”
80 dBA
110 kg
1,5 kW
Erhältlich in 230 V oder 110 V - 50/60 Hz (535: 400 V)
Erforderliche Sicherungen 10 A (230 V), 20 A (115 V)
* nur 535 400V
Gewicht: 170 kg
Motor: 400 V, 3Ø, 50 Hz, 1,35/1,7 kW, 35/70 min -1
Standardausstattung
300
Kompakt
1233 300/300A 535
535 400V
811A Schneidkopf
812A Schneidkopf
815A Schneidkopf
1/2”-3/4”, 1”-2” BSPT
Backen
928 Schneidkopf
2 1/2”-3” BSPT HS
Schneidbacken
Mineral-Gewindeschneidöl
-
-
x
x
-
-
5L.
-
-
x
x
x
x
5L.
x
-
-
x
-
-
5L.
x*
-
x*
x
-
-
5L.
*Optional
