6
4.2 Front LEDs
On the server’s front panel there are LED lights that inform you of the server’s
current status. Below is an explanation of each LED and its description.
LED Mode Status Description
On The device is ready Power
(Green)
Both
Off No power
Off The wireless mode is disabled.
WLAN Green
Blinking
The device is trying to connect to the AP or
station.
On Printing jobs are sending to the printer
Print Server
Off No printing jobs
On USB mass storage is ready to use
Off
No device is connected
Release is cancelled
Release is completed
USB Status
(Green) FTP/File
Server
Blinking
The “Release” button is clicked for over 5
seconds. The USB LED is blinking to alert
user to unplug the USB mass storage.
On
The LAN cable is connected to the network
device such as hub or switch.
Off No network connection.
LAN
(Green)
Both
Blinking
Network traffic transferring or receiving
through the LAN port.
