O-27
Cameo 2/3 Series User Guide
Printer Specifications
Environmental
Operating temperature: 14° to 122°F (-10° to 50°C)
Storage temperature: 5° to 140C°F (-15° to 60°C)
Relative humidity 10%-90% non-condensing
Intrusion Protection Rating (IP) 34*
* IP rating with optional protective boot installed
Cameo electronics automatically compensate for head temperature when printing. Protection circuitry
prevents damage due to excessive printhead temperatures.
When printing, there must be a wait time of one second between labels to remain within the optimal perfor-
mance specifications for this product.
Printing Characteristics
Cameo 2 Cameo 3
Printhead Width: 1.9” (48 mm) 2.83” (72 mm)
Number of Dots: 384 574
Printhead Life (Est.) 1,950,000” (50 Km nominal)
Technology Direct Thermal
Print Speed up to 3 IPS (76.2 mm/sec.)
Printhead Density 203 DPI (8 dots/mm)
Communications Specifications
Standard Built-in RS-232 port for one or two-way
Communications cable communication to terminal or other
host up to 38.4K BPS.
Programmable RTS/CTS (hardware) and
XON/XOFF protocols are supported.
Default communications parameters are:
Handshaking = RTS/CTS, Baud Rate = 19,200
Parity = None; Data Bits = 8; Stop Bits = 1
Optional Wireless Optional infrared communications via IrDA
Communications specifications.
Optional Bluetooth radio
Cameo 3 only:
Optional wireless LAN via 802.11b protocol
Physical
Cameo 2 Cameo 3
Weight* 1.15 lbs. (.5 kg) 1.4 lbs. (.64 kg) (CM3)
* Weight is with battery, no media loaded 1.6 lbs (.73 kg) (CM3w/ MCR)
