KIT
DTX700 Reference Manual 18
[Page displayed when a MIDI note number has
been selected directly using the [F1] button (PAD)]
NOTE
• The VoiceCategory parameter cannot be set to “ eSong” when
a MIDI note number is selected directly.
The parameter used for tuning will depend on the
type of voice assigned to the current pad.
[Drum sounds or waves (i.e., imported audio files)]
[When VoiceCategory is “Melody”]
Tuning (Tune)
Use this parameter to adjust the tuning of the assigned voice in
one-cent steps (0.01 = 1 cent)
Settings: -24.00 to +0.00 to +24.00
NOTE
• A cent is a unit of pitch defined as one hundredth of a semi-
tone. (100 cents = 1 semitone)
Note
Use this parameter to set the pitch of the assigned voice as a
MIDI note number.
Settings: C-2 to G8
Volume
Use this parameter to set the volume of the voice.
Settings: 0 to 127
Voice Panorama (Pan)
Use this parameter to set the stereo pan of the voice.
Settings: L63 to C to R63
The following parameters are used to adjust the tone
of the voice.
Attack Time (Attack)
Use this parameter to set the amount of time it takes from when
the pad is struck until the assigned voice reaches its peak volume.
Settings: -64 to +0 to +63
Decay Time (Decay)
Use this parameter to set the amount of time it takes the voice to
drop to a steady level after reaching its peak level.
Settings: -64 to +0 to +63
Release Time (Release)
Use this parameter to set the amount of time it takes for the voice
to fade out after sending a MIDI Note Off message.
Settings: -64 to +0 to +63
NOTE
• MIDI Note Off messages are not sent for pads and layers for
which the RcvKeyOff (Receive Key Off) parameter from the
Menu area’s Kit/MIDI/Assign page is set to “off”. Therefore, the
release-time setting has no effect in such a case.
• With certain types of voices, modifying the tone parameters
above will have very little effect.
KIT/VOICE 2/6
KIT/VOICE 3/6
