Release A 23
Section 2. Installation
Introduction
This section provides recommendations and procedures for inspecting, installing,
and testing the power supply.
Basic Setup Procedure
See Table 2.1 for a summary of the basic setup procedure and a view of the
subsections in this section. Use this procedure as a quick reference if you are
unfamiliar with the installation requirements for the power supply. Each step in the
procedure refers to subsequent sections which contain more details. Follow each step
in the sequence given.
Table 2.1 Basic Setup Procedure
Step # Description Action Reference
1 Inspection Perform an initial physical
inspection of the power
supply. “Inspection, Cleaning, and
Packaging” on page 24
2 Installation Install the supply (bench or
rack mount). Ensure
adequate ventilation. “Location, Mounting, and
Ventilation” on page 27
3 Input Power Connect AC input power. “AC Input Power Connection”
on page 28
4 Test Perform functional tests for
voltage mode operation,
current mode operation,
and front panel controls. “Functional Tests” on page 29
5 Load Connect the load. “Load Connection” on page 30
6 Sensing Connect sensing lines. “Remote Sensing” on page 33
