81
RW 420 User Guide
A
Accessories
Adjustable Shoulder Strap 45
Belt Clip 44
list of 71
Vehicle Cradle RW 220 50
Vehicle Cradle RW 420 46
B
Battery, charging 13
Battery pack
disposal of 52,55,56
installing 13
life, tips for extending 52
Bluetooth Device Address (BDA) 29
Bluetooth Networking Overview 29
C
Card Readers
Magnetic Stripe Reader 41
Smart Card Reader 43
Charger, Battery
Quad Charger 16
Charger, battery
LI72 Wall Chargers 13
Cleaning
exterior 54
interior 54
platen 54
printhead 54
tear bar 54
Communications
RS232 27
Connector signals 64
USB 28
Configuration Code, Product (PCC) 59
Controls, Operator 22
functions illustrated 22
LCD functions, extended 24
Cradle, Vehicle, RW 220 50
Installing printer in 50
removing printer from 51
Cradle, Vehicle, RW 420 24,46
Installing printer in 47
removing printer from 49
rotate display text when docking
46
D
Declaration of Conformity
802.11b (Compact Flash radio)
EU countries 34,36,39
Bluetooth radio (ZBR-3)
EU Countries 32
co-located 802.11b & Bluetooth
radios 39
Zebra 802.11g WLAN
37
Zebra Value Radio, 802.11b 36
L
Label, Configuration
printing 26
Label, configuration, example 60
Label Vista 30,31
M
Manual
CPCL Programming 30,31
EPL Programming 31
ZPL II Programming 31
Media, loading 18
fan-fold media 20
media Spacer, use of 20
P
Programming language
EPL 31
ZPL II 31
R
Radio Regulatory Information
802.11b/g Radio 37
EU countries 38
802.11b (Compact Flash radio)
EU countries 33
Bluetooth radio (RW-ZBR3)
EU countries 32
Co-located 802.11b & Bluetooth 39
Zebra Value Radio, 802.11b 35
EU Countries 35
S
Safety
Battery 11
Charger 11
Software 30
Specifications
Font/bar Codes 67
Media, RW 220 66
Media, RW 420 66
Memory/communications 63
Physical 68
printing 63
T
Technical Support
contacting 59
Troubleshooting
control panel indicators 55
entering communications diagnos-
tic mode 58
Index
continued
