72

RW Series User Guide Appendices

Appendix A

Interface Cables
RS232 Download Cable

Part Number BL17205-1; RW Mod Plug to 9-Pin DB PC Cable

PIN 1

PIN 10

6

(DSR)

SHIELD

(GND)

(DTR)
(CTS)
(RTS)

5
4
8
7

(RXD)

(TXD)

2

3

5 (DTR)

SHIELD

6 (GND)
7 (DSR)
8
9

(RTS)
(CTS)

10 PIN MOD Plug

(Printer Signals)

4

3

(TXD)

(RXD)

PIN 9

PIN 1

USB Cable

Part Number AT17010-1; USB A to USB Mini B Cable
