RW Series User Guide

• Remove the Docking Connector Cover from the bottom

of the printer, and retain it for future use. (Refer to Figure
22.)

• Place the bottom of the printer over the two pins in the

Cradle.

• Rock the top of the Printer into the Cradle and press ﬁrm-

ly until it latches in place.

• Ensure the Cradle power and charge indicators are lit and

turn the printer on.

If the charge indicator does not light up, unlatch the printer from the

Vehicle Cradle, lift it clear from the Cradle and re-seat it.

Refer to the Vehicle Cradle Installation Guide for more complete

information on the power and charge indicators

You can load media (including media from an external sup-

ply) and perform cleaning operations normally when the
RW 420 Printer is installed in the Cradle .
