Page 6
036-21121-002 Rev. A (0602)
6
Unitary Products Group
NOTES:
1. For condensing unit only. Does not include effect of evaporator motor power or heat.
2. Performance based on 15° superheat and 15° sub-cooling at condensing unit.
a. Increase capacity 1% for each 2° increase in sub-cooling.
b. Decrease capacity 1% for each 2° decrease in sub-cooling.
3. Sub-cooling in excess of 20° may result in excessively high condensing temperature with air on condenser above 115°F.
Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE
MODEL
SUCT. T/P
@ COMPR.
AIR TEMP ON CONDENSER
MODEL
SUCT. T/P
@ COMPR.
AIR TEMP ON CONDENSER
75°F
95°F
115°F
75°F
95°F
115°F
TEMP. PSIG MBH
KW
MBH
KW
MBH
KW
TEMP. PSIG
MBH
KW
MBH
KW
MBH
KW
H1RA018S06
35
61.5
16.2
1.66
13.1
1.84
11.0
1.96
H1RA048S06
H1RA048S(25,46)
35
61.5
39.9
4.18
32.3
4.63
27.0
4.94
40
68.5
17.7
1.67
14.9
1.88
12.8
2.04
40
68.5
43.6
4.21
36.7
4.73
31.4
5.14
45
76.0
19.3
169
16.7
1.92
14.2
2.11
45
76.0
47.6
4.26
41.1
4.84
34.9
5.32
50
84.0
20.8
1.70
18.5
1.96
15.9
2.18
50
84.0
51.1
4.28
45.5
4.94
39.0
5.48
H1RA024S06
35
61.5
21.0
2.23
17.0
2.46
14.2
2.63
H3RA060S06
35
61.5
49.4
4.15
43.8
5.13
38.2
6.34
40
68.5
22.9
2.24
19.3
2.52
16.5
2.74
40
68.5
54.0
4.19
48.2
5.14
42.3
6.35
45
76.0
25.0
2.27
21.6
2.58
18.3
2.83
45
76.0
58.4
4.27
52.4
5.25
46.3
6.47
50
84.0
26.8
2.28
23.9
2.63
20.5
2.92
50
84.0
62.7
4.32
56.9
5.38
50.2
5.61
H2RA030S06
35
61.5
25.1
2.68
20.3
2.97
17.0
3.17
H1RA060S(25,46)
35
61.5
54.4
4.46
50.5
4.74
46.3
5.08
40
68.5
27.4
2.70
23.1
3.04
19.7
3.30
40
68.5
60.1
4.44
56.0
4.83
51.6
5.18
45
76.0
29.9
2.74
25.8
3.10
21.9
3.41
45
76.0
65.8
4.53
61.6
4.92
56.9
5.26
50
84.0
32.1
2.75
28.6
3.17
24.5
3.51
50
84.0
71.9
4.62
67.5
5.01
62.6
5.36
H2RA036S06
H1RA036 S(25,46)
35
61.5
30.5
3.28
24.7
3.64
20.6
3.88
H1RA076S(25,46)
35
61.5
77.4
5.06
63.4
6.08
50.6
7.35
40
68.5
33.3
3.31
28.1
3.72
24.0
4.04
40
68.5
84.5
5.21
69.2
6.23
55.4
7.49
45
76.0
36.4
3.35
31.4
3.80
26.7
4.18
45
76.0
91.8
5.37
75.3
6.38
60.3
7.64
50
84.0
39.1
3.36
34.8
3.88
29.9
4.31
50
84.0
99.4
5.54
81.7
6.55
65.6
7.80
H1RA042S06
H1RA042S(25,46)
35
61.5
35.8
3.83
28.9
4.25
24.2
4.53
H1RA090S(25,46)
35
61.5
84.0
8.28
72.9
9.11
61.7
9.87
40
68.5
39.1
3.86
32.9
4.34
28.2
4.72
40
68.5
92.5
8.50
80.8
9.41
68.9 10.26
45
76.0
42.6
3.90
36.8
4.53
31.3
4.87
45
76.0
101.3
8.73
89.0
9.72
76.5 10.66
50
84.0
45.8
3.93
40.8
4.63
35.0
5.03
50
84.0
110.4
8.95
97.5 10.03 84.4 11.08
C
A
B
DIMENSIONS - 1 Phase
UNIT
MODEL
DIMENSIONS
(INCHES)
REFRIGERANT
CONNECTION
LINE SIZE
A
1
B
C
Liquid
Vapor
018
17
35
23
3/8”
5/8”
024
17
35
23
5/8”
030
19
35
23
3/4”
036
19
35
23
3/4”
042
25
35
23
3/4”
048
27
37
27
7/8”
060
27
37
27
7/8”
DIMENSIONS - 3 Phase
UNIT
MODEL
DIMENSIONS
(INCHES)
REFRIGERANT
CONNECTION
LINE SIZE
A
1
1
Including Fan guard.
B
C
Liquid
Vapor
036
19
35
23
3/8”
3/4
042
25
35
23
3/8
3/4
048
27
37
27
3/8”
7/8
060
39
37
27
3/8”
7/8
076
26
43
32
1/2
1-1/8
090
32
43
32
1/2
1-1/8
