York H*RA036 THRU 090 - Manual (Page 4)

036-21121-002 Rev. A (0602)
4 Unitary Products Group
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
W
RATED
CFM
NET MBH SEER + TXV
W/O TDR
SEER + TXV 1
+ TDR*
EER
TOTAL SENS.
H1RA018S06
575
725
14,17 G1FA024S14,17 650 18.0 13.3 10.00 - 9.20
14 G1FA030S14 650 19.0 14.1 10.50 - 9.80
- G1HD024 655 18.5 13.7 10.50 - 10.00
17 G1NA024S17G 650 18.0 12.5 10.00 - 9.40
14,17 G1UA024S14,17 650 18.0 13.3 10.00 - 9.20
14 G1UA030S14 650 19.0 14.1 10.50 - 9.80
14,17 G2FD024S14,17 650 19.0 14.1 10.50 - 9.80
17 G2FD030S17 650 19.4 14.4 10.50 - 9.90
14 G2FD035S14 650 19.4 14.4 10.50 - 9.90
H1RA024S06
700
900
14,17 G1FA024S14,17 850 23.8 17.6 10.00 - 9.15
14 G1FA030S14 800 24.4 18.1 10.50 - 9.55
14 G1FA036S14 800 24.0 18.1 10.00 - 9.00
17,21 G1FA036S17,21 850 25.0 18.5 10.00 - 8.95
- G1HD024 820 23.2 17.2 10.00 - 8.80
- G1HD036 800 24.4 18.1 10.60 - 9.80
17 G1NA030S17H 800 23.6 17.5 10.00 - 9.00
21 G1NA030S21B 800 23.6 17.5 10.00 - 9.00
14,17 G1UA024S14,17 850 23.8 17.6 10.00 - 9.15
14 G1UA030S14 800 24.4 18.1 10.50 - 9.55
14 G1UA036S14 800 24.0 18.5 10.00 - 9.00
17,21 G1UA036S17,21 850 25.0 18.5 10.00 - 8.95
14,17 G2FD024S14,17 800 24.4 18.5 10.50 - 9.55
17 G2FD030S17 850 25.0 18.5 10.60 - 9.65
14 G2FD035S14 850 25.0 18.9 10.60 - 9.65
17 G2FD036S17 850 25.6 18.9 10.70 - 9.70
H2RA030S06
875
1125
14 G1FA030S14 1000 28.0 20.7 10.00 - 9.30
14 G1FA036S14 1000 29.2 20.3 10.25 - 9.40
17,21 G1FA036S17,21 1000 29.0 21.5 10.45 - 9.45
- G1HD036 1000 29.6 21.9 10.00 - 9.55
17 G1NA030S17K 1000 29.0 20.4 10.00 - 9.30
21 G1NA030S21M 1050 29.0 20.4 10.00 - 9.20
14 G1UA036S14 1000 29.2 20.3 10.25 - 9.40
17,21 G1UA036S17,21 1000 29.0 21.5 10.45 - 9.45
17 G2FD030S17 1000 29.0 21.5 10.30 - 9.45
14 G2FD035S14 1000 29.0 21.5 10.30 - 9.45
21 G2FD036S21 1000 30.0 22.2 10.50 - 9.65
H2RA036S06
1050
1350
14 G1FA036S14 1200 33.6 24.9 10.00 - 9.10
17,21 G1FA036S17,21 1200 33.6 24.9 10.00 - 9.10
17 G1FA048S17 1200 35.0 25.9 10.30 - 9.40
21,24 G1FA048S21,24 1200 36.0 26.6 10.40 - 9.40
- G1HD036 1200 34.4 25.5 10.00 - 8.90
- G1HD048 1165 34.8 25.8 10.00 - 8.95
17 G1NA036S17J 1200 34.4 25.5 10.00 - 9.20
21 G1NA036S21C 1200 34.4 25.5 10.00 - 9.30
14 G1UA036S14 1200 33.6 24.9 10.00 - 9.10
17,21 G1UA036S17,21 1200 33.6 24.9 10.00 - 9.10
17 G1UA048S17 1200 35.0 25.9 10.30 - 9.40
21,24 G1UA048S21,24 1200 36.0 26.6 10.40 - 9.40
14 G2FD035S14 1200 33.4 24.7 10.00 - 9.10
17 G2FD036S17 1200 33.8 25.0 10.00 - 9.20
21 G2FD036S21 1200 33.8 25.0 10.00 - 9.20
21 G2FD042S21 1200 34.4 25.5 10.15 - 9.30
17 G2FD046S17 1200 34.4 25.5 10.15 - 9.30
For Notes See Page 5.
