Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO.
H1RA024S06
INDOOR COIL MODEL NO.
G1FA024S14, 17
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
600
800
1000
ID DB (°F)
85
80
75
70
85
80
75
70
85
80
75
70
ID WB (°F)
72
67
62
57
72
67
62
57
72
67
62
57
75
T.C.
28.3
25.9
22.7
21.4
28.7
25.1
24.4
21.8
27.5
26.6
24.5
20.9
S.C.
16.9
16.9
15.4
17.0
17.7
16.8
17.0
17.8
17.1
18.0
17.3
17.3
K.W
2.04
1.94
1.78
1.78
2.05
1.87
1.89
1.80
1.97
1.98
1.89
1.72
85
T.C.
28.5
26.0
22.8
21.4
28.9
25.2
24.4
21.8
27.7
26.7
24.6
20.9
S.C.
17.5
17.5
16.0
17.6
18.5
17.6
17.9
18.7
18.0
19.0
18.2
18.3
K.W
2.25
2.14
1.95
1.95
2.28
2.06
2.07
1.96
2.18
2.18
2.07
1.88
95
T.C.
26.9
24.5
21.4
20.1
27.3
23.7
23.0
20.6
26.2
25.2
23.0
19.8
S.C.
17.4
17.4
15.9
17.5
18.5
17.6
17.9
18.8
18.1
19.0
18.3
18.4
K.W
2.42
2.28
2.06
2.06
2.44
2.20
2.20
2.08
2.34
2.32
2.21
1.99
105
T.C.
24.7
22.4
19.5
18.3
24.8
21.6
20.9
18.6
23.8
22.8
21.1
17.9
S.C.
16.8
16.8
15.3
16.9
17.9
16.9
17.3
17.9
17.6
18.4
17.6
17.5
K.W
2.52
2.37
2.15
2.14
2.54
2.30
2.29
2.17
2.43
2.43
2.30
2.07
115
T.C.
22.0
19.9
17.4
16.3
22.2
19.3
18.6
16.9
21.2
20.4
18.8
16.2
S.C.
15.8
15.7
14.3
15.8
17.0
16.2
16.2
16.7
16.7
17.5
16.8
16.1
K.W
2.60
2.45
2.23
2.20
2.63
2.36
2.37
2.25
2.51
2.50
2.37
2.17
125
T.C.
19.4
17.5
15.3
14.2
19.5
16.9
16.3
15.1
18.6
17.9
16.5
14.6
S.C.
14.7
14.7
13.3
14.6
16.0
15.4
15.1
15.4
15.9
16.6
15.9
14.6
K.W
2.68
2.53
2.31
2.26
2.71
2.43
2.44
2.33
2.59
2.57
2.44
2.27
NOTE:
ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler
Coil
T.C.
S.C.
KW
N1AHB0806
G2FD024S14,17
0.98
0.98
0.91
N1AHB0806
G2FD030S17
1.00
1.00
0.93
F2RP/F2FP024
0.94
0.94
0.93
F2RP/F2FP030
0.94
0.95
0.93
G1FA030S14
0.98
0.98
0.91
G1HD024
0.93
0.93
0.94
G1HD036
0.98
0.98
0.89
G1NA030S17H
0.94
0.95
0.94
G1NA030S21B
0.944
0.946
0.939
G1UA024S14,17
0.95
0.95
0.93
G1UA030S14
0.98
0.98
0.91
G1UA036S17,21
1.00
1.00
1.00
G2FD024S14,17
0.98
0.98
0.91
G2FD030S17
1.00
1.00
0.93
G2FD035S14
1.00
1.00
0.93
G2FD036S17
1.02
1.02
0.94
MDD30BSD
0.94
0.95
0.94
