Prestige 792H G.SHDSL Router
36-2 VPN/IPSec Setup
Figure 36-2 Menu 27 VPN/IPSec Setup
36.2 IPSec Summary Screen
Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 IPSec Summary. This is a summary
read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by selecting an index number and
then configuring the associated submenus.
Figure 36-3 Menu 27.1 IPSec Summary
The following table describes the fields in this menu.
Table 36-1 Menu 27.1 IPSec Summary
FIELD DESCRIPTION EXAMPLE
# This is the VPN policy index number. 1
Menu 27.1 – IPSec Summary
# Name A Local Addr Start - Addr End / Mask Encap IPSec Algorithm
Key Mgt Remote Addr Start - Addr End / Mask Secure GW Addr
--- -------- - ------------------ ------------------ ------ ------------------
001 Taiwan Y 192.168.1.35 192.168.1.38 Tunnel ESP DES MD5
IKE 172.16.2.40 172.16.2.46 193.81.13.2
002 zw50 N 1.1.1.1 1.1.1.1 Tunnel AH SHA1
IKE 4.4.4.4 255.255.0.0 zw50test.zyxel.
003 China N 192.168.1.40 192.168.1.42 Tunnel ESP DES MD5
IKE N/A N/A 0.0.0.0
004
005
Select Command= None Select Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
3. View IPSec Log
Enter Menu Selection Number:
