Prestige 791R G.SHDSL Router
Remote Node TCP/IP Configuration 24-7
Table 24-2 Remote Node Network Layer Options
FIELD DESCRIPTION EXAMPLE
Private This determines if the Prestige will include the route to this remote node in
its RIP broadcasts. If set to Yes, this route is kept private and not included
in RIP broadcast. If No, the route to this remote node will be propagated
to other hosts through RIP broadcasts.
No
RIP Direction Press [SPACE BAR] and then [ENTER] to select the RIP Direction.
Options are Both, In Only, Out Only or None.
None
Version Press [SPACE BAR] and then [ENTER] to select the RIP version.
Options are RIP-1, RIP-2B or RIP-2M.
RIP-1
Multicast IGMP-v1 sets IGMP to version 1, IGMP-v2 sets IGMP to version 2 and
None disables IGMP.
None
IP Policies You can apply up to four IP Policy sets (from 12) by typing in their
numbers separated by commas. Configure the filter sets in menu 25 first
(see the IP Policy Routing chapter) and then apply them here.
3, 4, 5, 6
Bridge Options
Ethernet Addr
Timeout (min) See the chapter on Bridging Setup for information on bridging.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to
cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
24.3.1 My WAN Addr Sample IP Addresses
The following diagram explains the sample IP addresses to help you understand the field of My Wan Addr
in Menu 11.3. My WAN Addr indicates the local Prestige WAN IP while Rem IP Addr indicates the peer
WAN IP.
