64 6238 Wi-Fi Router with VOIP User’s Guide 6238-A2-ZB20-10
• PSTN Route Rule— For incoming calls using PSTN, this is the line (line 1
or line 2) that the call is received through. You can select auto so that it
automatically selects an open line.
• Route PSTN to VoIP— For incoming PSTN calls you can select whether or
not you want to route the call to use VoIP.
• Route VoIP to PSTN— For incoming VoIP calls you can select whether or
not you want to route the call to a PSTN line and which VoIP line you want
to be able to route to the PSTN line.
Note: There are 2 VoIP lines and only 1 PSTN line, therefore only one
of the VoIP lines can have the option of being routed to a PSTN line. The
options here are to select which VoIP line (line 1 or 2) will have the service
of being routed to a PSTN line.
• Locale Selection— The location of the router.
• Remote Server for SIP Log Messages— If you enable the remote server,
then fill out the following two fields: Log IP Address and Log Port.
• Log IP Address— The IP address of the remote server for SIP log message.
• Log Port— The port number of the remote server.
Phone1 & Phone2 Default Connections
Factory default configuration set the Default Connect to PSTN to Disabled and
assigned Phone1 and Phone2 to connect to the VoIP network as shown below:
When the Default Connect to PSTN is enabled for either Phone1 or Phone2 or
Both, as shown below:
