TABLE 9: SIDE SUPPLY AIR BLOWER PERFORMANCE - 230 & 460 VOLT
1
MODEL #
DNH
(Cooling/
Heating)
MTR
SPD
EXTERNAL STATIC PRESSURE - IWG
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
CF
M
W
A
TTS
030
HI - - - - - - 1200 560 1110 537 1019 514 929 491 809 473 - - - - - -
MED 1110 383 1055 368 999 353 944 338 865 319 785 299 - - - - - - - - - -
LOW 998 372 906 333 813 294 - - - - - - - - - - - - - - - -
036
HI - - - - - - - - - - 1447 754 1360 722 1264 692 1169 663 1073 633 977 603
MED - - - - 1483 682 1420 655 1341 625 1262 596 1183 566 1075 534 966 501 - - - -
LOW 1384 625 1336 605 1287 584 1239 564 1167 537 1094 509 1022 482 903 460 - - - - - -
042
HI - - - - 1705 847 1622 818 1535 786 1447 754 1360 722 1364 692 1169 663 1073 633 - -
MED 1610 735 1547 708 1483 682 1420 655 1341 625 1262 596 1183 566 1075 534 - - - - - -
LOW 1384 625 1336 605 1287 584 1239 564 1167 537 1094 509 - - - - - - - - - -
048
HI 1906 982 1857 960 1809 938 1758 913 1706 888 1648 861 1590 834 1445 783 1301 731 - - - -
MED 1734 848 1693 821 1651 794 1595 764 1539 734 1461 693 1382 653 1266 613 - - - - - -
LOW 1532 700 1508 683 1458 667 1444 643 1404 620 1348 593 1291 566 - - - - - - - -
060
(only
575 volts)
HI - - 2444 1433 2380 1400 2313 1363 2245 1325 2169 1285 2092 1245 1902 1168 1711 1092 1521 1015 - -
MED 2281 1265 2227 1225 2172 1185 2099 1140 2025 1095 1922 1035 1819 975 1665 915 1512 855 - - - -
LOW 1914 1045 1885 1020 1855 995 1805 960 1754 925 1684 885 1613 945 - - - - - - - -
060
(3 tube)
(only 230 &
460 volts)
HEAT 1500 245 1500 297 1500 348 1500 400 1500 470 1500 540 1500 610 1500 680 1500 750 1500 820 1500 890
060
(4 & 5 tube)
(only 230 &
460 volts)
HEAT 1700 390 1700 443 1700 497 1700 550 1700 620 1700 690 1700 760 1700 830 1700 900 1700 970 - -
060
(factory
setting)
(only 230 &
460 volts)
COOL 1800 460 1800 515 1800 570 1800 625 1800 690 1800 755 1800 820 1800 962 1800 1105 - - - -
060
(field setting)
(only 230 &
460 volts)
COOL 2000 640 2000 700 2000 760 2000 820 2000 928 2000 1035 - - - - - - - - - -
1. Above data includes allowances for a dry evaporator coil, gas heat exchanger and no filters. For additional pressure drops, refer
to Tables 12 and 13.
