TABLE 7: DNH060 COOLING CAPACITIES - 5 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,700 CFM 1,800 CFM 1,900 CFM 2,000 CFM 2,100 CFM
WB °F WB °F WB °F WB °F WB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
66.8 63.1 58.2 57.0 68.2 64.4 59.4 58.2 69.5 65.6 60.6 59.3 69.3 65.4 60.3 59.1 69.0 65.1 60.1 58.9
TOTAL POWER
INPUT kW
5.06 4.96 5.02 4.83 5.13 5.03 5.10 4.90 5.21 5.11 5.17 4.97 5.33 5.24 5.30 5.09 5.46 5.36 5.43 5.22
Se
n
s
ib
le
C
apac
it
y
MB
H
1
Ent
e
ri
ng Dry
Bul
b
°
F
86 42.8 53.5 58.2 57.0 44.6 55.8 59.4 58.2 46.5 58.1 60.6 59.3 47.8 59.5 60.3 59.1 49.1 61.0 60.1 58.9
83 37.9 48.7 57.7 57.0 39.4 50.6 59.1 58.2 41.0 52.5 60.6 59.3 41.9 53.6 60.3 59.1 42.9 54.8 60.1 58.9
80 33.1 43.8 52.8 54.2 34.3 45.4 54.7 56.1 35.4 47.0 56.6 58.1 36.0 47.7 57.5 58.5 36.6 48.5 58.5 58.9
77 28.2 39.0 48.0 49.4 29.1 40.2 49.5 50.9 29.9 41.4 51.1 52.5 30.1 41.8 51.6 52.6 30.3 42.3 52.2 52.6
74 23.4 34.1 43.1 44.5 23.9 35.0 44.3 45.7 24.4 35.9 45.5 47.0 24.2 35.9 45.7 46.7 24.1 36.0 45.9 46.4
71 - 29.3 38.3 39.7 - 29.8 39.1 40.6 - 30.4 40.0 41.5 - 30.0 39.8 40.8 - 29.7 39.7 40.1
68 - 24.5 33.4 34.8 - 24.6 33.9 35.4 - 24.8 34.4 35.9 - 24.1 33.9 34.9 - 23.5 33.4 33.8
95 °F
NET CAP.
MBH
66.1 61.3 56.8 55.2 67.0 62.1 57.6 56.0 67.9 63.0 58.4 56.7 67.7 62.7 58.2 56.6 67.4 62.5 58.0 56.4
TOTAL POWER
INPUT kW
5.66 5.60 5.58 5.37 5.72 5.66 5.64 5.43 5.78 5.72 5.70 5.49 5.86 5.80 5.77 5.56 5.94 5.87 5.85 5.63
S
ensible
Cap
a
city
MBH
1
Ent
e
rin
g
Dr
y
Bulb °F
86 42.9 53.4 56.8 55.2 44.6 55.5 57.6 56.0 46.4 57.6 58.4 56.7 47.7 59.1 58.2 56.6 49.0 60.6 58.0 56.4
83 38.1 48.6 55.3 55.2 39.5 50.3 56.9 56.0 40.8 52.0 58.4 56.7 41.8 53.2 58.2 56.6 42.8 54.3 58.0 56.4
80 33.2 43.7 50.5 51.7 34.3 45.1 52.1 53.4 35.3 46.5 53.7 55.0 35.9 47.3 54.6 55.7 36.5 48.1 55.5 56.4
77 28.4 38.9 45.6 46.9 29.1 39.9 46.9 48.2 29.8 40.9 48.1 49.5 30.0 41.4 48.7 49.8 30.2 41.8 49.2 50.1
74 23.5 34.0 40.8 42.1 23.9 34.7 41.7 43.0 24.2 35.4 42.6 43.9 24.1 35.5 42.8 43.9 24.0 35.5 43.0 43.8
71 - 29.2 35.9 37.2 - 29.5 36.5 37.8 - 29.9 37.1 38.4 - 29.6 36.9 38.0 - 29.3 36.7 37.6
68 - 24.3 31.1 32.4 - 24.3 31.3 32.6 - 24.3 31.5 32.9 - 23.7 31.0 32.1 - 23.0 30.5 31.3
105 °F
NET CAP.
MBH
62.5 57.1 53.0 51.7 63.5 58.0 53.8 52.6 64.5 58.9 54.6 53.4 64.2 58.6 54.3 53.1 63.8 58.2 54.0 52.8
TOTAL POWER
INPUT kW
6.29 6.17 6.12 6.02 6.36 6.24 6.19 6.09 6.43 6.31 6.26 6.16 6.55 6.43 6.38 6.27 6.68 6.55 6.50 6.39
Sen
s
ib
le Cap
a
city
MBH
1
E
n
te
ring
Dry
Bu
lb
°
F
86 41.8 51.8 53.0 51.7 43.6 54.0 53.8 52.6 45.5 56.2 54.6 53.4 47.1 56.7 54.3 56.1 48.7 57.3 54.0 52.8
83 36.9 47.0 52.2 51.7 38.4 48.9 53.4 52.6 39.9 50.7 54.6 53.4 41.2 52.3 54.3 53.1 42.5 53.8 54.0 52.8
80 32.1 42.2 48.5 48.2 33.2 43.7 50.2 49.9 34.4 45.2 52.0 51.6 35.3 46.4 52.4 52.2 36.2 47.6 52.8 52.8
77 27.3 37.3 43.6 43.3 28.1 38.5 45.0 44.7 28.9 39.6 46.4 46.1 29.4 40.5 46.5 46.3 29.9 41.3 46.5 46.5
74 22.4 32.5 38.8 38.5 22.9 33.3 39.8 39.5 23.3 34.1 40.9 40.5 23.5 34.6 40.6 40.4 23.7 35.0 40.3 40.3
71 - 27.6 34.0 33.6 - 28.1 34.6 34.3 - 28.5 35.3 35.0 - 28.7 34.7 34.5 - 28.8 34.0 34.0
68 - 22.8 29.1 28.8 - 22.9 29.5 29.1 - 23.0 29.8 29.4 - 22.8 28.8 28.6 - 22.5 27.8 27.8
115 °F
NET CAP.
MBH
59.0 52.9 49.1 48.2 60.1 53.8 50.0 49.1 61.2 54.8 50.9 50.0 60.7 54.4 50.5 49.6 60.2 54.0 50.1 49.2
TOTAL POWER
INPUT kW
6.92 6.75 6.67 6.67 7.00 6.83 6.75 6.75 7.08 6.90 6.82 6.82 7.25 7.07 6.99 6.99 7.41 7.23 7.15 7.15
Sensib
le Cap
a
city
MB
H
1
En
ter
ing Dry
Bu
lb °F
86 40.7 50.3 49.1 48.2 42.6 52.6 50.0 49.1 44.6 54.8 50.9 50.0 46.5 54.4 50.5 49.6 48.4 54.0 50.1 49.2
83 35.8 45.4 49.1 48.2 37.4 37.4 50.0 49.1 39.0 49.4 50.9 50.0 40.6 51.3 50.5 49.6 42.2 53.3 50.1 49.2
80 31.0 40.6 46.5 44.6 32.2 42.2 48.4 46.4 33.5 43.8 50.2 48.2 34.7 45.4 50.2 48.7 35.9 47.0 50.1 49.2
77 26.1 35.7 41.7 39.8 27.0 37.0 43.2 41.2 27.9 38.3 44.7 42.6 28.8 39.5 44.3 42.8 29.7 40.8 43.8 43.0
74 21.3 30.9 36.8 34.9 21.8 31.8 38.0 36.0 22.4 32.8 39.2 37.1 22.9 33.6 38.4 36.9 23.4 34.5 37.6 36.7
71 - 26.0 32.0 30.1 - 26.6 32.8 30.8 - 27.2 33.6 31.6 - 27.7 32.5 31.0 - 28.3 31.3 30.5
68 - 21.2 27.1 25.2 - 21.4 27.6 25.6 - 21.7 28.1 26.0 - 21.8 26.6 25.1 - 22.0 25.1 24.2
125 °F
NET CAP.
MBH
55.5 48.7 45.2 44.7 56.7 49.7 46.2 45.7 57.9 50.8 47.2 46.7 57.3 50.2 46.7 46.2 56.7 49.7 46.2 45.7
TOTAL POWER
INPUT kW
7.50 7.30 7.20 7.30 7.60 7.40 7.30 7.40 7.70 7.50 7.40 7.50 7.90 7.70 7.60 7.70 8.20 7.90 7.80 7.90
S
ensible
Cap
a
c
ity
MBH
1
Ent
e
ri
ng Dry
Bulb
°
F
86 39.6 48.7 45.2 44.7 41.6 51.1 46.2 45.7 43.6 53.5 47.2 46.7 45.9 52.0 46.7 46.2 48.1 50.6 46.2 45.7
83 34.7 43.9 46.0 44.7 36.4 46.0 46.6 45.7 38.1 48.1 47.2 46.7 40.0 50.4 46.7 46.2 41.9 52.8 46.2 45.7
80 29.9 39.0 44.5 41.0 31.2 40.8 46.5 42.9 32.6 42.5 48.5 44.8 34.1 44.5 48.0 45.2 35.6 46.5 47.4 45.7
77 25.0 34.2 39.7 36.2 26.0 35.6 41.3 37.7 27.0 37.0 43.0 39.2 28.2 38.6 42.1 39.3 29.4 40.3 41.1 39.4
74 20.2 29.3 34.8 31.3 20.8 30.4 36.1 32.5 21.5 31.4 37.4 33.7 22.3 32.7 36.2 33.4 23.1 34.0 34.9 33.1
71 - 24.5 30.0 26.5 - 25.2 30.9 27.3 - 25.9 31.9 28.2 - 26.8 30.3 27.5 - 27.7 28.6 26.9
68 - 19.6 25.1 21.7 - 20.0 25.7 22.1 - 20.4 26.4 22.6 - 20.9 24.4 21.6 - 21.5 22.4 20.6
1. These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
