ZyXEL NWA-3160 Series User’s Guide
241
C
H A P T E R
21
Product Specifications
The following tables summarize the ZyXEL Device’s hardware and firmware features.
Table 93 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions 190x 135 x 40 mm
Weight NWA-3160: 420g
NWA-3163: 420g
NWA-3165: 392g
Power 12V DC, 1.5 A max. (There is no tolerance for the DC input voltage.)
Ethernet Ports Auto-negotiating: 10 Mbps or 100 Mbps in either half-duplex or full-duplex
mode.
Auto-crossover: Use either crossover or straight-through Ethernet cables.
Power over Ethernet
(PoE)
IEEE 802.3af compliant.
Console Port One MIL-C-5015 style RS-232 console port
(PS/2 connector; Mini Din 6-pin)
Antenna Specifications NWA-3160: Two 2dBi Dual Band (2.4 GHz/5 GHz) attachable dipole
antennas.
NWA-3163: Two 3dBi 2.4GHz attachable dipole antennas.
NWA-3165: Three 1.8dBi embedded dipole antennas
