Unitary Products Group

All dimensions are in inches. They are subject to change
without notice. Certified dimensions will be provided upon
request.

Physical and Electrical Data

MODEL

HABE-F018S HDBE-F024S HCBE-F030S HABE-F036S HBBE-F042S HBBE-F048S HCBE-F060S

Unit Supply Voltage

208-230V, 1

φ, 60Hz

Normal Voltage Range

1

187 to 252

Minimum Circuit Ampacity

8.5

10.5

16.9

18.1

17.8

20.6

33.5

Max. Overcurrent Device Amps

2

15

15

25

25

30

35

50

Min. Overcurrent Device Amps

3

15

15

20

20

20

25

35

Compressor Type

Recip

Recip

Recip

Scroll

Scroll

Scroll

Scroll

Compressor Amps

Rated Load

6.4

8.0

12.8

13.5

13.2

15.5

25.6

Locked Rotor

36

40.5

68

73

95

109

150

Crankcase Heater

No

No

No

No

No

No

No

Fan Motor Amps

Rated Load

0.5

0.5

0.8

1.5

1.5

1.5

1.5

Fan Diameter Inches

22

22

22

22

24

24

24

Fan Motor

Rated HP

1/15

1/15

1/8

1/4

1/4

1/4

1/4

Nominal RPM

830

830

1075

850

850

850

850

Nominal CFM

2,100

2,000

2,800

3,300

3,300

3,300

3,600

Coil

Face Area Sq Ft

15.71

15.71

23.58

23.58

22.50

27.00

27.00

Rows Deep

1

1

1

1

2

2

2

Fin /Inch

22

22

22

18

18

18

18

Liquid Line Set OD (Field Installed)

3/8

3/8

3/8

3/8

3/8

3/8

3/8

Vapor Line Set OD (Field Installed)

3/4

3/4

7/8

7/8

1 1/8

1 1/8

1 1/8

Unit Charge (Lbs - Oz)

4

5 - 9

6 - 0

8 - 2

9 - 14

14 - 15

15 - 5

16 - 5

Charge Per Foot, oz.

0.68

0.68

0.70

0.68

0.76

0.76

0.76

Operating Weight Lbs

170

181

193

219

240

264

279

1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15

feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

A

B

C

Unit

Model

Dimensions

(Inches)

Refrigerant Connection

Service Valve Size

A

1

1. Included Fan Guard.
* Adapter fitting required for 1-1/8” line set.

B

C

Liquid

Vapor

018

27

37

27

3/8

3/4

024

27

37

27

030

39

37

27

7/8

036

39

37

27

042

32

43

32

1-1/8

048

38

43

32

060

38

43

32

7/8*
