ZyXEL Communications P-2900-4HB - Manual (Page 52)

Chapter 5 LAN Setup
P-2900-4HB User’s Guide
52
5.3 The Static DHCP Screen
Click Advanced Setup > LAN > Static DHCP to open the Static DHCP screen.
A DHCP server may assign a different IP address to a computer when its DHCP
Primary DNS
Server Enter the IP addresses of the DNS servers. The DNS servers are
passed to the DHCP clients along with the IP address and the subnet
mask.
Secondary DNS
Server As above.
Remote DHCP
Server If Relay is selected in the DHCP field above then enter the IP address
of the actual remote DHCP server here.
TCP/IP
IP Address
Enter the IP address of your ZyXEL Device in dotted decimal notation,
for example, 192.168.100.1 (factory default).
IP Subnet Mask Type the subnet mask assigned to you by your ISP (if given).
RIP Direction Select the RIP direction from None, Both, In Only and Out Only. The
RIP Direction field controls the sending and receiving of RIP packets.
RIP Version Select the RIP version from RIP-1, RIP-2B and RIP-2M. The RIP
Version field controls the format and the broadcasting method of the
RIP packets that the ZyXEL Device sends (it recognizes both formats
when receiving).
Multicast IGMP (Internet Group Multicast Protocol) is a network-layer protocol
used to establish membership in a multicast group. The ZyXEL Device
supports both IGMP versions 1 (IGMP-v1) and 2 (IGMP-v2). Select
None to disable it.
Back Click Back to return to the previous screen without saving.
Apply Click Apply to save your changes back to the ZyXEL Device.
Cancel Click Cancel to begin configuring this screen afresh.
Table 8 Advanced Setup > LAN > LAN Setup (continued)
LABEL DESCRIPTION
