Page 18

Chapter 2 Fiber-optic Connection
MC1000-SFP-FP User’s Guide
18
"
SFP transceiver installation orientation varies depending on your device. Your
SFP transceiver comes with a mechanism that prevents incorrect insertion. Do
NOT force or twist the SFP transceiver into a slot.
6 Lock the transceiver into place (if your transceiver has a locking mechanism).
Figure 9 Lock Transceiver
"
See the transceiver User’s Guide for more information.
2.5 Install Fiber-optic Cable
Follow these procedures to install the fiber-optic cable.
2.5.1 Attach Wire Mounts
The purpose of the wire mounts is to securely wrap extra length of fiber optic cable you may
have within the MC1000-SFP-FP in order to prevent it from being damaged. Remove the
adhesive cover from the wire mounts and attach them to the sides of the MC1000-SFP-FP as
shown.
