036-21315-001 Rev. A (0502)
4 Unitary Products Group
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
W
RATED
CFM
NET MBH SEER + TXV
W/O TDR
SEER + TXV 1
+ TDR*
EER
TOTAL SENS.
H1RE024S06
700
900
14 G1FA036S14 800 25.0 18.0 13.85 - 12.30
17,21 G1FA036S17,21 800 24.8 17.9 13.85 - 12.20
- G1HD036 800 25.0 18.1 14.00 - 12.35
17 G1NA036S17L 800 24.0 16.6 13.50 - 12.00
21 G1NA048S21D 800 24.0 16.6 13.50 - 12.00
14 G1UA036S14 800 25.0 18.0 13.85 - 12.30
17,21 G1UA036S17,21 800 24.8 17.9 13.85 - 12.20
17 G2FD030S17 800 24.8 17.9 13.85 - 12.20
14 G2FD035S14 800 24.8 17.9 13.85 - 12.20
17 G2FD036S17 800 25.2 18.1 14.00 - 12.35
21 G2FD036S21 800 25.2 18.1 14.00 - 12.45
H1RE030S06
875
1125
14 G1FA036S14 1000 28.4 20.0 13.00 - 11.75
17,21 G1FA036S17,21 1000 28.4 20.0 13.00 - 11.65
21,24 G1FA048S21,24 1000 30.0 21.8 14.00 - 12.40
- G1HD048 1000 30.0 21.5 14.00 - 12.40
17 G1NA036S17L 1000 29.0 20.0 - 13.50 11.95
24 G1NA042S24W 1000 29.0 20.7 - 14.00 12.00
21 G1NA048S21D 1000 29.0 20.0 - 13.50 11.95
14 G1UA036S14 1000 28.4 20.0 13.00 - 11.75
17,21 G1UA036S17,21 1000 28.4 20.0 13.00 - 11.65
21,24 G1UA048S21,24 1000 30.0 21.8 14.00 - 12.40
17 G2FD030S17 1000 28.4 20.4 13.00 - 11.65
17 G2FD036S17 1000 28.8 20.7 13.10 - 11.80
21 G2FD036S21 1000 28.8 21.0 13.10 - 12.10
21,24 G2FD048S21,24 1000 30.2 21.8 - 14.00 12.50
H1RE036S06
1050
1350
21,24 G1FA048S21,24 1200 35.2 25.3 14.00 - 12.30
- G1HD048 1200 34.8 25.0 13.75 - 12.30
17 G1NA036S17L 1200 33.0 23.4 - 13.00 11.30
24 G1NA042S24W 1200 34.6 25.0 - 14.00 12.00
21 G1NA048S21D 1200 33.0 23.4 - 13.00 11.30
21,24 G1UA048S21,24 1200 35.2 25.3 14.00 - 12.30
17 G2FD036S17 1200 34.0 24.5 13.35 - 11.80
21 G2FD036S21 1200 34.0 24.8 13.35 - 12.05
21 G2FD042S21 1200 34.8 25.4 13.70 - 12.10
17 G2FD046S17 1200 35.0 25.6 14.00 - 12.20
21,24 G2FD048S21,24 1200 35.2 25.7 14.00 - 12.45
H2RE042S06
1225
1575
21,24 G1FA048S21,24 1400 39.0 28.4 - 13.50 11.45
21,24 G1FA060S21,24 1400 40.5 29.6 - 14.00 11.80
- G1HD048 1400 39.0 28.4 - 13.25 11.50
24 G1NA042S24W 1400 40.5 29.5 - 14.00 11.75
21 G1NA048S21D 1400 39.0 27.3 - 13.00 11.50
21,24 G1UA048S21,24 1400 39.0 28.4 - 13.50 11.45
21,24 G1UA060S21,24 1400 40.5 29.6 - 14.00 11.80
21 G2FD042S21 1400 39.0 28.2 - 13.25 11.35
17 G2FD046S17 1400 39.0 28.6 - 13.50 11.45
21,24 G2FD048S21,24 1400 39.5 28.9 - 13.50 11.60
24 G2FD060S24 1400 40.5 29.6 - 14.00 11.80
H2RE048S06
1400
1800
21,24 G1FA048S21,24 1600 45.0 32.6 - 13.40 11.50
21,24 G1FA060S21,24 1600 46.5 33.9 - 13.85 11.80
- G1HD048 1600 45.0 32.4 - 13.25 11.45
24 G1NA042S24W 1500 46.5 32.8 - 14.00 11.85
21 G1NA048S21D 1400 44.0 29.0 - 13.00 11.50
21,24 G1UA048S21,24 1600 45.0 32.6 - 13.40 11.50
21,24 G1UA060S21,24 1600 46.5 33.9 - 13.85 11.80
21,24 G2FD048S21,24 1600 45.5 33.2 - 13.50 11.60
24 G2FD060S24 1600 46.5 33.9 - 13.85 11.80
24 G2FD061H24 1600 47.0 34.3 - 14.00 11.90
For Notes See Page 5.
