York H*RE024 User Manual
Page 2
036-21315-001 Rev. A (0502)
2
Unitary Products Group
Physical and Electrical Data
MODEL
H1RE024S06
H1RE030S06
H1RE036S06
H2RE042S06
H2RE048S06
H2RE060S06
Unit Supply Voltage
208 / 230 - 1 – 60
Normal Voltage Range
1
187 to 252
Minimum Circuit Ampacity
12.1
14.9
18.1
17.8
20.6
31.8
Max Overcurrent Device Amps
2
20
20
25
30
35
50
Compressor Type
3
Inertia
Inertia
Scroll
C
Scroll
C
Scroll
C
Scroll
B
Compressor Amps
Rated Load
9.3
10.9
13.5
13.2
15.5
24.3
Locked Rotor
57
64
73
95
109
150
Crankcase Heater
No
No
No
No
No
No
Fan Motor Amps
Rated Load
.5
1.3
1.3
1.3
1.3
1.4
Fan Diameter Inches
22
22
22
24
24
24
Fan Motor
Rated HP
1/15
1/4
1/4
1/4
1/4
1/3
Nominal RPM
830
825
825
825
825
1100
Nominal CFM
2,260
3,300
3,300
3,300
3,300
3,500
Coil
Face Area Sq Ft
19.65
23.58
23.58
22.5
27.0
27.0
Rows Deep
1
1
1
2
2
2
Fin /Inch
18
18
18
18
18
18
Liquid Line OD
3/8
3/8
3/8
3/8
3/8
3/8
Vapor Line OD
7/8
7/8
7/8
1 1/8
1 1/8
1 1/8
Unit Charge (Lbs - Oz)
4
8 - 0
9 - 14
9 - 6
14 - 0
14 - 3
15 - 13
Charge Per Foot, oz.
0.70
0.70
0.70
0.76
0.76
0.76
Operating Weight Lbs
209
228
219
240
264
270
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with superscript “B” are Bristol scrolls. All scrolls listed with superscripts “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15
feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
C
A
B
All dimensions are in inches. They are subject to change with
out notice. Certified dimensions will be provided upon request.
1. Included Fan Guard
* Reducer Fan Guard
Unit
Model
Dimensions
(Inches)
Refrigerant
Connection
Line Size
A
B
C
Liquid
Vapor
024
33
37
27
3/8
7/8
030
39
37
27
036
39
37
27
042
32
43
32
1-1/8
048
38
43
32
060
38
43
32
