Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO.
H1RE036S06
INDOOR COIL MODEL NO.
G1UA048S21, 24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
1000
1200
1400
ID DB
85
80
70
85
80
70
85
80
70
ID WB
72
67
57
72
67
57
72
67
57
75
T.C.
40.0
36.9
34.3
41.3
38.1
35.7
42.0
38.9
36.7
S.C.
25.4
24.4
23.4
27.6
26.3
25.5
29.6
27.9
27.2
K.W
1.98
1.96
1.94
1.99
1.97
1.95
2.00
1.98
1.96
85
T.C.
38.6
35.6
32.7
39.6
36.6
34.0
40.2
37.3
34.9
S.C.
24.8
23.8
22.8
27.0
25.8
24.9
29.1
27.6
26.6
K.W
2.21
2.18
2.17
2.22
2.19
2.18
2.23
2.20
2.19
95
T.C.
37.2
34.2
31.0
37.8
35.2
32.4
38.4
35.8
33.0
S.C.
24.2
23.3
22.3
26.4
25.3
24.2
28.5
27.2
25.9
K.W
2.44
2.41
2.40
2.45
2.42
2.41
2.46
2.42
2.42
105
T.C.
35.5
32.3
29.6
36.1
33.1
30.6
36.7
33.7
31.2
S.C.
23.5
22.6
21.7
25.6
24.6
23.5
27.6
26.5
25.3
K.W
2.75
2.72
2.72
2.75
2.73
2.72
2.76
2.73
2.73
115
T.C.
33.7
30.4
28.1
34.4
31.1
28.7
35.0
31.7
29.4
S.C.
22.8
21.8
21.1
24.7
23.9
22.8
26.8
25.8
24.6
K.W
3.06
3.04
3.03
3.06
3.04
3.02
3.07
3.04
3.03
125
T.C.
31.9
28.5
26.7
32.7
29.1
26.9
33.3
29.7
27.6
S.C.
22.2
21.1
20.5
23.9
23.1
22.1
25.9
25.1
24.0
K.W
3.37
3.36
3.34
3.37
3.35
3.32
3.38
3.35
3.33
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler
Coil
T.C.
S.C.
KW
N1AHB1206
G2FD036S17
0.97
0.97
1.01
N1AHB1206
G2FD046S17
0.99
1.01
1.00
N1VSB12
G2FD046S17
1.00
1.01
0.99
N1VSC16
G2FD048S21
1.02
1.02
0.92
N1AHD14
G2FD048S24
1.01
1.02
0.99
N1AHD14
G2FD060S24
1.02
1.03
0.98
F2FP045
1.02
1.01
0.99
F2RP/F2FP042
0.98
0.98
1.01
F2RP/F2FP036
0.98
0.98
0.99
G1FA048S21,24
1.00
1.00
1.00
GFD042S21
0.99
1.00
1.00
G2FD036S17
0.97
0.97
1.01
G2FD036S21
0.97
0.98
0.99
G2FD046S17
0.99
1.01
1.00
G2FD048S21,24
1.00
1.02
0.99
G1HD048S
0.99
0.99
0.99
G1NA036S17L
0.94
0.92
1.02
G1NA042S24W
0.98
0.99
1.01
GNA048S21D
0.94
0.92
1.02
G1UA048S21,24
1.00
1.00
1.00
Variable Speed
Furnace
Coil
T.C.
S.C.
KW
P1DUB16V
G2FD036S17
0.98
0.97
0.95
P1DUC20V
G1FA048S21
1.03
1.00
0.89
P1DUC20V
G1UA048S21
1.03
1.00
0.89
P1DUC20V
G2FD036S21
0.98
0.98
0.93
P1DUC20V
G2FD048S21
1.02
1.02
0.90
P1XDB12V
G2FD036S17
0.99
0.97
0.97
P1XDD20V
G2FD048S24
1.03
1.02
0.97
P1XUB12V
G2FD036S17
0.98
0.97
0.95
